Fibre-optic networks could be used to monitor earthquakes

02 April 2020

The same optical fibres that deliver high-speed internet and HD video to our homes could provide an inexpensive observatory for mapping earthquake trouble spots.

(Image: Shutterstock)

“Fibre-optic cables are the backbone of modern telecommunications and we have demonstrated that we can turn existing networks into extensive seismic arrays to assess ground motions during earthquakes,” said U-M seismologist Zack Spica, first author of the paper published in the journal JGR Solid Earth.

The study was conducted using a prototype array at Stanford University. Co-authors include researchers at Stanford and from Mexico and Virginia.

“This is the first time that fibre-optic seismology has been used to derive a standard measure of subsurface properties that is used by earthquake engineers to anticipate the severity of shaking,” said geophysicist Greg Beroza, a co-author on the paper and the Wayne Loel Professor in Stanford’s School of Earth, Energy & Environmental Sciences (Stanford Earth).

To transform a fibre-optic cable into a seismic sensor, the researchers connect an instrument called a laser interrogator to one end of the cable. It shoots pulses of laser light down the fibre. The light bounces back when it encounters impurities along the fibre, creating a “backscatter signal” that is analysed by a device called an interferometer.

Changes in the backscatter signal can reveal how the fibre stretches or compresses in response to passing disturbances, including seismic waves from earthquakes. The technique is called distributed acoustic sensing, or DAS, and has been used for years to monitor the health of pipelines and wells in the oil and gas industry.

The new study in JGR Solid Earth extends previous work with the three-mile Stanford test loop by producing high-resolution maps of the shallow subsurface – which scientists can use to see which areas will undergo the strongest shaking in future earthquakes, Beroza said.

In addition, the study demonstrates that optical fibres can be used to sense seismic waves and obtain velocity models and resonance frequencies of the ground – two parameters that are essential for ground-motion prediction and seismic-hazard assessment.

Spica and his colleagues say their results are in good agreement with an independent survey that used traditional techniques, thereby validating the methodology of fibre-optic seismology.

This approach appears to have great potential for use in large, earthquake-threatened cities such as San Francisco, Los Angeles, Tokyo and Mexico City – where thousands of miles of optical cables are buried beneath the surface.

“What’s great about using fibre for this is that cities already have it as part of their infrastructure, so all we have to do is tap into it,” Beroza said.

Many of these urban centres are built atop soft sediments that amplify and extend earthquake shaking. The near-surface geology can vary considerably from neighbourhood to neighbourhood, highlighting the need for detailed, site-specific information.

Yet, getting that kind of information can be a challenge with traditional techniques, which involve the deployment of large seismometer arrays – thousands of such instruments in the Los Angeles area, for example.

“In urban areas, it is very difficult to find a place to install seismic stations because asphalt is everywhere,” Spica said. “In addition, many of these lands are private and not accessible, and you cannot always leave a seismic station standing alone because of the risk of theft.

“Fibre optics could someday mark the end of such large scale and expensive experiments. The cables are buried under the asphalt and crisscross the entire city, with none of the disadvantages of surface seismic stations.”

The technique would likely be fairly inexpensive, as well, Spica said. Typically, commercial fibre-optic cables contain unused fibres that can be leased for other purposes, including seismology.

For the moment, traditional seismometers provide better performance than prototype systems that use fibre-optic sensing. Also, seismometers sense ground movements in three directions, while optical fibres only sense along the direction of the fibre.

The next phase of the project involves a much larger test array. A 27-mile loop was formed recently by linking optical fibres on Stanford’s campus with fibres at several other nearby locations.
