Method makes plastic transparent and conductive

13 July 2020

A method to make plastic conductive and more transparent could improve large touchscreens, LED light panels, and window-mounted infrared solar cells.

Jay Guo holds a sheet of flexible transparent conductor on the University of Michigan’s College of Engineering North Campus. (Image credit: Robert Coelius/University of Michigan Engineering, Communications & Marketing)

They provide a recipe to help other researchers find the best balance between conductivity and transparency by creating a three-layer anti-reflection surface. The conductive metal layer is sandwiched between two dielectric materials that allow light to pass through easily. The dielectrics reduce the reflection from both the plastic and metal layer between them.

“We developed a way to make coatings with high transparency and conductivity, low haze, excellent flexibility, easy fabrication, and great compatibility with different surfaces,” says Jay Guo, professor of electrical engineering and computer science at the University of Michigan, who led the work.

Previously, Guo’s team showed it was possible to add a layer of metal onto a plastic sheet to make it conductive – a very thin layer of silver that, by itself, reduced the transmission of light by roughly 10%.

Light transmission through plastic is a little lower than through glass, but its transparency can improve with anti-reflection coatings. Guo and his colleague Dong Liu, a visiting professor from Nanjing University of Science and Technology, realised that they could make an anti-reflection coating that was also conductive.

“It was taken for granted that the transmittance of the conductor is lower than that of the substrate, but we show that this is not the case,” says Chengang Ji, first author of the study in Nature Communications, who worked on the project as a PhD student in electrical and computer engineering before graduating in 2019.

The team chose aluminium oxide and zinc oxide as dielectrics. On the side closest to the light source, the aluminium oxide reflects less light back to the source than the plastic surface would. Then comes the metal layer, composed of silver with a tiny amount of copper in it, just 6.5 nanometres thick, and then zinc oxide helps guide the light into the plastic surface. Some light still reflects back where the plastic meets the air on the opposite side, but overall, the light transmission is better than the plastic alone. The transmittance is 88.4%, up from 88.1% for the plastic alone.

With the theory results, the team anticipates that other researchers will be able to design similar sandwich-style flexible, highly transparent conductors, which allow even more light through than the plastic alone.

“We tell people how transparent a dielectric-metal-dielectric conductor could be, for a target electrical conductance. We also tell them how to achieve this high transmittance step-by-step,” Liu says.

The tricks are selecting the right dielectrics and then figuring out the right thickness for each to suppress the reflection of the thin metal. In general, the material between the plastic and metal should have a higher refractive index, while the material nearest the display or light source should have a lower refractive index.

Guo is continuing to move the technology forward, collaborating on a project that uses transparent conductors in solar cells for mounting on windows. These could absorb infrared light and convert it to electricity while leaving the visible spectrum to brighten the room. He also proposes large panel interactive displays and car windshields that can melt ice the way rear windows can.

The university has licensed the technology to the start-up company Zenithnano, co-founded by Guo, to pursue commercialisation. Guo is also a professor of mechanical engineering, macromolecular science and engineering, and applied physics.

Source: University of Michigan

The original article can be found on Futurity
